| Weight | 50t |
| Driving Wheels | 5ft 6ins |
| Boiler Pressure | 140psi |
| Cylinders | Two Outside – 18in x 24in |
| Tractive Effort | 14,020lbf |
| Weight | 50t |
| Driving Wheels | 5ft 6ins |
| Boiler Pressure | 140psi |
| Cylinders | Two Outside – 18in x 24in |
| Tractive Effort | 14,020lbf |
30 locomotives were supplied by Beyer Peacock between 1877 and 1879 and a further four in 1881. 26 were built by Dübs and Company during 1880 and 1881 and 8 were built in Australia by the Atlas Engineering Works situated in Sydney and delivered in 1881 and 1882. In total 68 locomotives were supplied to the New South Wales Government Railway (NSWGR).
The locomotive design is a development of the London Metropolitan Railway class A 4-4-0T locomotive built by Beyer Peacock and first used in 1864. One of these locomotives (Metropolitan Railway No 23) is preserved in Britain at the London Transport Museum.
The first batch of locomotives supplied by Beyer Peacock were placed in service as class 79 locomotives. They were the first locomotives to be imported with Westinghouse continuous air-brakes already fitted.
They were employed hauling express passenger and mail trains.
In 1895 one of the class was converted to a 4-4-2T tank engine for use on the Sydney suburban services. By 1902 a further 19 had been converted to 4-4-2T tank engines at Eveleigh Railway Workshops and became CC79 class locomotives and then the Z13 class in 1924.
The remaining 4-4-2 tender engines were then classed as C80 which was later changed to Z12.
The 20 rebuilt locomotives were displaced from suburban passenger duties following introduction of powerful 4-6-4T locomotives from 1903. They were then deployed on various branch line duties including the Yass Tramway and the Picton-Mittagong Loop Line, while others were used as shunters.
This is locomotive (1307) was the built by Beyer Peacock in Manchester for the New South Wales Government Railway in 1877 as a 4-4-0 locomotive.
In 1894 it was rebuilt as a 4-4-2T engine for use at Sydney on suburban passenger trains.
It almost lasted to the very end of NSWGR steam, being withdrawn from shunting service at Clyde in 1972 after a working life of over 94 years. By this time it had covered 1,383,190 miles
1307 was then stored at Enfield and was added to the collection of the New South Wales Rail Transport Museum (NSWRTM).
The locomotive was moved to Thirlmere in 1975 together with other NSWRTM exhibits, and was stored away from public view from 1983. It became increasingly rusted and derelict through the years of open storage, and apparently some parts were removed in the mid-1980’s to further the planned restoration of classmate 1308.
In 1999 the locomotive was removed from the storage sidings at Thirlmere and transported to Yass Railway Museum. Here it was repainted and cosmetically restored for display at the former Yass railway station.
By 2010 a further, more comprehensive restoration and repainting effort was in progress. 1307 is a very appropriate exhibit at the Yass Railway Museum because it had worked on the Yass Tramway from time to time between 1910 and the 1950’s.
There are five other members of the original 68 delivered preserved.
Two other class Z13 locomotives were preserved
- 1301 built by Beyer Peacock in 1877 as works number 1624
- 1308 built by Beyer Peacock in 1877 as works number 1620
Three are preserved as Z12 locomotives
- 1210 built by Beyer Peacock in 1878 as work number 1767
- 1219 built in 1879 by Dübs and Company as works number 1270
- 1243 built in 1882 by Atlas Engineering Company in Australia
